커민스 ISB140-30

터보

Engine model ISB140-30 Engine type 4 cylinders in line Displacement 3.9L Rated Power (KW@RPM) 103kW(140HP)@2500rpm Peak Torque(Nm@RPM) 450 N.m @1200-2100rpm Emission Standard Euro III/EuroIV Cummins diesel engine ISB140-30 technique specification Bore*stroke 102*120mm Intake method Turbochager&Intercooled Fuel systeme DENSO High Pression Common Rail Cooling method Fluid Cooling 7.0L Governor Type Electronic Control CM2220 Compression Ratio 18:1 Fuel Consumption: 20.8L/hr@Rated Power Starting System Electrical Starting Motor 24V/510A Lowest Starting Temp .(with/without auxiliary system) -10℃/-41℃ Cummins diesel engine ISB140-30 trade information Warranty time 1year or 1500h Engine Size(L*W*H): 791mm*772mm*831mm Weight net 337Kg Delivary port Qingdao Delivary time 15 working days Trade termes FOB/CIF/CNP Payement termes T/T，L/C All the spare parts for Cummins ISB140-30 are available;
