새니 STC500E

Company Information Shanghai Jipan Trade Co.,Ltd. is a professional vehicle exporting company.It has been in this business over 20 years and have strong stock to meet market requirement. It has professional repairing team,loading team,purchase team and exporting team.We can provide best service and perfect cooperation feeling.Now We have ambulance,fair engines,truck mounted crane,crawler crane,forklift,excavator,bulldozer...and so on in stock.And have many Chinese or Japanese,American brand for choice. Please contact without hesitation.

Parameter Value Overall Length 14260mm Overall Width 2650mm Overall Height 3800mm Total Mass of the Whole Machine 41000kg Engine Model Weichai WP9 / Yuchai YCK09 series Engine Maximum Power Weichai version: 247kW/1900rpm; Yuchai version: 265kW/1900rpm Engine Maximum Output Torque Weichai version: 1600N·m/(1000-1400)rpm; Yuchai version: 1600N·m/(1100-1450)rpm Maximum Driving Speed 90km/h Minimum Turning Radius 12m Maximum Climbing Gradient 47% Maximum Rated Total Lifting Capacity 50t Minimum Rated Radius 3m Swing Radius of Turret Tail 4.04m Maximum Lifting Moment of Basic Boom 2043kN·m Maximum Lifting Moment of Fully Extended Boom 1239kN·m Outrigger Span (Transverse × Longitudinal) 7.4m × 6.05m Basic Boom Length 12.24m Longest Main Boom Length 45.5m Longest Main Boom + Jib Length 61.5m Maximum Single-Rope Speed of Main Winch (No Load) 120m/min Maximum Single-Rope Speed of Auxiliary Winch (No Load) 120m/min Full Extension/Retraction Time of Boom 100/120s Full Lifting/Lowering Time of Boom 60/90s Slewing Speed 0-2r/min
