새니 STC500E

Fly Jib ,Hook ,Counter Weight, ETC. We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Nina Whatsapp: +86 18055199047 Mobile:+86 18055199047 Wechat:18055199047 Email: Fly Jib ,Hook ,Counter Weight, ETC. Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

起升能力参数 最大额定起重量：50t 最大额定起重力矩：1644kN·m-2107kN·m 最大起升高度 - 全伸臂：45.5m-62m 最大起升高度 - 基本臂 + 副臂：61.5m-62m 作业速度参数 主卷扬最大单绳速度：120m/min-145m/min 起重臂全伸时间：90s-100s 起重臂全缩时间：110s-120s 起重臂全起时间：45s-60s 起重臂全落时间：70s-90s 最大回转速度：2r/min-2.5r/min 发动机参数 发动机型号：玉柴 YCK08330-61、潍柴 WP9H336E62 等 额定功率：243/2200kW/rpm（玉柴 YCK08330-61）、247/1900kW/rpm（潍柴 WP9H336E62） 行驶参数 最高行驶速度：85km/h-90km/h 最小转弯半径：12m 最大爬坡度：45%-47% 接近角：18°-19° 离去角：11°-14° 最小离地间隙：250mm-320mm 整机规格参数 整机全长：13960mm-14420mm 整机全宽：2650mm-2800mm 整机全高：3700mm-3885mm 支腿跨距（横 × 纵）：6.05m×7.4m-8.0m×6.24m 重量参数 整机总重量：39000kg-42000kg 最大配重：6t+2.5t-9.8t
