Cummins ISDe230 31
Price excl. VAT
POA
Print
INFO
Product group
Engines
Brand / model
Cummins ISDe230 31
Year of manufacture
2018
Condition
New/unused
Machine location
Jining, Shandong, China
Country
China
General grade
Mascus ID
837AEAC9
DETAILS
Internal stock no.
ISDe230 31
Latest inspection
yes
Engine output
169 kW (230 hp)
Part ID
ISDe230 31
Full service history
Yes
Manufacturing / Serial number
ISDe230 31
Transport weight
700 kg
Transport dimensions (LxWxH)
1400 x 1000 x 1400 mm
RPM
2500
Emission level
Stage IIIB / Tier IV interim
Condition info/guarantee
ISO9001
Production country
China
Delivery terms
FCA, CPT, FOB, CFR, CIF, EXW
Other information
Cummins ISDe230-31 Diesel Engine for Vehicle
General Information of Cummins ISDe230-31 Diesel Engine for Vehicle
Engine Model ISDe230-31
Engine Type 6 Cylinders, in Line
Displacement 6.7 L
Bore*Stroke(mm) 107 * 124
Compression Ratio 17.3 : 1
CPL Number -
Net Weight (with flywleel & alternator) 530 Kg
Overall Diemension(L*W*H) 1060mm*700mm*860mm
Technical Specification of Cummins ISDe230-31 Diesel Engine for Vehicle
Certification Euro III
Aspiration Turbocharged & Inter-cooled
Fuel System Bosch Pump
Electrical System(Starter Motor/Alternator) 12V/500A; 24V/250A
Lowest Starting Temp.(with/without auxiliary system) -10℃/-25℃
Engine Cooling Fluid Volume 9.4 L
Performance Data of Cummins ISDe230-31 Diesel Engine for Vehicle
Rated Power/Speed 169kW/230HP @ 2500rpm
Max.Torque/Speed 900N.m @ 1400 rpm
Fuel Consumption @ Rated Power 50.4 l/hr
Idel Speed 600~800 rpm
Max. Continuous Running Altitude 2000 m
Jining Haoduo Import and export co., Ltd.
Second floor, First section, No.2 building,Jining Lantian Boiler 272000 Jining 济宁 Shandong 山东 China
