커민스 6CTA8.3-M220

Cummins 6CTA8.3-M220 Marine Propulsion Diesel Engine General Information of Cummins 6CTA8.3-M220 Marine Propulsion Diesel Engine Engine Model 6CTA8.3-M220 Engine Type 6 Cylinders in Line Displacement 8.3 L Bore*Stroke(mm) 114 * 135 CPL Number CPL DC21 Net Weight (with flywleel & alternator) 604 Kg Overall Diemension(L*W*H) 1360mm*780mm*988mm Technical Specification of Cummins 6CTA8.3-M220 Marine Propulsion Diesel Engine Marine Certification CCS Aspiration Turbocharged & Water Intercooled Fuel System BYC PB Pump/R801 Governor Electrical System(Starter Motor/Alternator) 12V/24V Lowest Starting Temp without auxiliary system -12℃ Engine Cooling Fluid Volume 12.6 L Performance Data of Cummins 6CTA8.3-M220 Marine Propulsion Diesel Engine Rated Power/Speed 164 kW/220HP /1800rpm Max. Power/Speed 166 kW/242HP /2270rpm Fuel Consumption / Rated Power 247g/Kw.h Fuel Consumption / Standby Power 247g/Kw.h Idel Speed 800rpm
