새니 SY 60 C

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Nina Whatsapp: +86 18055199047 Mobile:+86 18055199047 Wechat:18055199047 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs

Basic Parameters: Total machine weight: 6,000 kg Bucket capacity: 0.25 m³ Engine model: Kubota V2607 Rated power: 36 kW/2000 rpm Maximum torque: 206.9 N·m/rpm Displacement: 2.615 L Climbing ability: 70% (35°) Swing speed: 10.3 rpm Ground pressure: 31 kPa Bucket digging force: 45 kN Arm digging force: 33 kN Travel speed: 4.1/2.4 km/h Travel Components: Standard track width: 400 mm Top rollers per side: 1 piece Track shoes per side: 42 pieces Carrier rollers per side: 5 pieces Oil and Coolant Capacities: Final drive: 2×0.9 L Fuel tank: 125 L Hydraulic oil tank: 85 L Engine oil: 9.6 L Radiator: 6.5 L total length (during transportation) 5915 mm, total width (transportation/operation) 2025 mm, total height (during transportation) 2560 mm, upper structure width 1860 mm, dozer blade height 340 mm, track gauge (transportation/operation) 1600 mm, minimum ground clearance 315 mm, tail swing radius 1635 mm, track ground contact length 2190 mm, and track length 2710 mm. Its working range includes: maximum digging height 5610 mm, maximum dumping height 3910 mm, maximum digging depth 3830 mm, maximum vertical digging depth 3055 mm, maximum digging radius 6070 mm, minimum swing radius 2540 mm, and maximum height at minimum swing radius 4440 mm.
