구보다 U 17

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Nina Whatsapp: +86 18055199047 Mobile:+86 18055199047 Wechat:18055199047 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs

Item Specification Bucket Capacity 0.035 m³ Standard Bucket Width (with/without side teeth) 450 / 400 mm Operating Weight 1735 / 1805 kg Overall Length 3545 mm Overall Height 2340 mm Overall Width 900 / 1240 mm Minimum Ground Clearance 150 mm Engine Model D902-E4 Total Displacement 898 cc Rated Output Power 16.5 PS (12.1 kW) / 2400 rpm Maximum Digging Height 3540 mm Maximum Dumping Height 2440 mm Maximum Digging Depth 2310 mm Maximum Vertical Digging Depth 1910 mm Maximum Digging Radius 3900 mm Boom Offset (Left/Right) 385 / 510 mm Minimum Front Swing Radius (when swinging) 1440 (1210) mm Minimum Rear Swing Radius 620 mm Maximum Digging Force (Bucket) 15.2 kN (1550 kgf) Track Type Rubber / Steel Tracks Track Width 230 mm Total Track Length 1585 mm Wheelbase 1230 mm Track Gauge 760 / 1010 mm Travel Speed (Low/High) 1.9 / 3.9 km/h Climbing Ability 30° Swing Speed 9.5 rpm Dozer Blade Width 990 / 1240 mm Dozer Blade Height 265 mm Lifting Distance (Above/Below GL) 280 / 190 mm Hydraulic Pump Type Variable Displacement Pump *2 + Gear Pump *2 Swing Motor Type Gerotor Motor Travel Motor Type 2-Speed Piston Hydraulic Motor Fuel Tank Capacity 19 litres
