구보다 KX 161

We're from Shanghai Jipan Trade Co.,Ltd.I'm the Sales Manager, specializing in selling used machines from various brands, including excavators,truck cranes,crawler cranes,and so on.With extensive export experience, our machines are sold well in Europe, America, Africa,and other regions, receiving rave reviews and a high repurchase rate. We uphold the principles of integrity and quality, and have a professional service team to provide you with one-stop service, ensuring accurate, efficient, and safe delivery of your machines.We are committed to building long-term relationships with every customer from around the world with competitive prices and superior quality. Contact: Jason WhatsApp/Mobile:0086 13675656717 WeChat:+86 13675656717 Shipping Method: Container Vessel, Bulk Carrier, Flatbed Vessel, or RoRo Vessel.If you don't have your own shipping agent, we can ship on your behalf and offer you the lowest possible shipping rates.

Parameter configuration of Kubota KX161 excavator Specification The working weight of the entire machine (kg) is 5675 Bucket capacity (m³):0.22 Origin: Japan Tonnage (tons)6 Performance Rotational speed (rpm):9.3 Walking speed (km/h)2.5/4.6 Climbing ability (%)58/30 degrees Bucket digging force (kN)39 Power system Engine model: Kubota V2403-M Rated power (kw/rpm)34.6/2200 Displacement (L)2.434 The cooling method is water cooling Hydraulic system The main pump type is variable pump + gear pump The walking hydraulic motor type is a plunger hydraulic motor The rotary hydraulic motor type is a plunger hydraulic motor Is the hydraulic crushing pipeline a standard configuration Oil capacity Fuel tank (L)70 Main body size The total length of transportation (mm) is 5540 The total transportation width (mm) is 2110 The total transportation height (mm) is 2540 Track grounding length (mm)1990 The total length of the track (mm) is 2500 Track plate width (mm)550 The total width of the tracks (mm) is 2110 Track gauge (mm):1560 Minimum ground clearance (mm):320 The minimum turning radius (mm) of the front working device is 2420/1955 Rear end turning radius (mm):1090 Scope of work Maximum excavation radius (mm):6290 The maximum excavation radius (mm) of the shutdown face is 6165 Maximum excavation depth (mm):3860 Maximum excavation height (mm):5770 Maximum unloading height (mm):4125 The maximum vertical excavation depth (mm) is 2995 Boom rotation Angle (left/right °)50/80 The width × height (mm) of the bulldozer board is 2110×390 The bulldozer shovel lifts or deepens (mm)455/375
