구보다 KX 161
부가세 제외가격
6
즐겨찾기
공유
검색 저장출력
INFO
제품군
소형 굴삭기 7톤 미만
제작사/모델
구보다 KX 161
제작년도
2023
사용시간
820 시간
국가
중국
일반 등급
1
2
3
4
5
마스쿠스 ID
558D1AE8
가격
화폐 선택
세부정보
재고번호
1
제조번호
1
동력 형식
디젤
최근검사
2025-10-21
기존 차주 수
1
하부 구성품 상태
good condition
총 중량
5675 kg
등록번호
1
매연 등급
Stage V / Tier V
트랙 폭
550 mm
버켓 용량
0.22 m3
장비크기
5540 x 2110 x 2540 mm
오리지널 컬러
Orange
엔진
Diesel
엔진 출력
34.6 kW (47.0 마력)
엔진 제조사
Kubota
타이어 브랜드
Original
상태 정보/보증
1 year
제품 국가
일본
운송 조건
FCA, FOB, CIF, EXW
증명서
미국 환경 보호국(EPA), 유럽 위원회(CE)
어태치먼트
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET
TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET
CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours:24 hours, holidays and Sundays
Contact: Lily
Whatsapp: +86 13696501072
Mobile:+86 17756597429
Wechat:17756597429
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
부속품
냉/난방 조절
퀵 커플러
고무트랙
스켈레톤 버킷
회전 비컨
조이스틱 컨트롤
표준 굴착 버켓
기타 정보
Kubota KX161-3S Excavator Parameter Configuration
Specifications
Operating Weight (kg) 5675
Bucket Capacity (m³) 0.22
Origin Japan
Tonnage (ton) 6
Manufacturer Joint Venture/Imported
Power Conventional Power
Bucket Backhoe
Manufacturer Joint Venture/Imported
Power Conventional Power
Performance
Rotation Speed (rpm) 9.3
Travel Speed (km/h) 2.5/4.6
Climbing Ability (%) 58/30 degrees
Bucket Digging Force (kN) 39
Power System
Engine Model Kubota V2403-M
Rated Power (kw/rpm) 34.6/2200
Displacement (L) 2.434
Cooling Method Water-cooled
Hydraulic System
Main Pump Type Variable Pump + Gear Pump
Travel Hydraulic Motor Type Piston Hydraulic Motor
Rotation Hydraulic Motor Type Piston Hydraulic Motor
Standard Hydraulic Breaker Pipe Yes
Oil Capacity
Fuel Tank (L) 70
Overall Dimensions
Transport Length (mm) 5540
Transport Width (mm) 2110
Transport Height (mm) 2540
Track Ground Contact Length (mm) 1990
Track Total Length (mm) 2500
Track Plate Width (mm) 550
Track Total Width (mm) 2110
Track Gauge (mm) 1560
Minimum Ground Clearance (mm) 320
Minimum Turning Radius of Front Working Device (mm) 2420/1955
Rear Turning Radius (mm) 1090
Operating Range
Maximum Digging Radius (mm) 6290
Maximum Digging Radius at Ground Level (mm) 6165
Maximum Digging Depth (mm) 3860
Maximum Digging Height (mm) 5770
Maximum Dumping Height (mm) 4125
Maximum Vertical Digging Depth (mm) 2995
Arm Rotation Angle (Left/Right °) 50/80
Bulldozer Blade Width × Height (mm) 2110 × 390
Bulldozer Blade Lift or Push Depth (mm) 455/375
