얀마 Vio 17

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Lily Whatsapp: +86 13696501072 Mobile:+86 17756597429 Wechat:17756597429 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Yanmar Vio17 Excavator Parameter Configuration specification Power: Traditional power Joint ventures/imports Bucket backhoe Tonnage (tons) 1 The working weight of the whole machine (kg) is 1700 Bucket width (mm) 450 Bucket capacity (m³) 0.05 performance Rotational speed (rpm) 9.5 Travel speed (km/h) is 3.8 high and 1.9 low Ground Specific Pressure (Kpa) Rubber Tracks 28/Steel 29 Bucket digging force (kN) 15.2 dynamical system Engine model Yanmar 3TNV70-XBV Rated power (kw/rpm) 10.1/2200 Number of cylinders (pcs) 3 Cooling method: Water cooling Working form: vertical water cooling; 3 cylinders; Direct injection Hydraulic system The maximum flow rate (l/min) of the main pump is 17.6×2 13.2 Main overflow set pressure (Mpa) 20.6×2 16.7×1 Oil capacity Fuel tank (L) 20 Body size Total length of transport (mm) 3450 Total Transport Width (mm) 1280 (950) Total height of transport (mm) 2370 The overall height of the cab (mm) is 2370 Total track length (mm) 1525 Track shoe width (mm) 230 Total track width (mm) 1280 Track gauge (mm) 1050 Minimum ground clearance (mm) 175 The minimum turning radius of the front working device (mm) is 1520 The rear end slewing radius (mm) is 640 Scope of work Maximum digging radius (mm) 3710 Maximum digging depth (mm) 2200 Maximum digging height (mm) 3690 Maximum unloading height (mm) 2630 Maximum vertical digging depth (mm) 1850 Boom slewing angle (left/right°) 42/75 Width × height of bulldozer plate (mm) 950/1280×235 Bulldozer shovel lifting or pushing depth (mm) 260/205
