볼보 EC 250 D
부가세 제외가격
7
즐겨찾기
공유
검색 저장출력
INFO
제품군
대형 굴삭기 29톤 이상
제작사/모델
볼보 EC 250 D
제작년도
2022
사용시간
746 시간
국가
중국
일반 등급
1
2
3
4
5
마스쿠스 ID
681E6D26
가격
화폐 선택
세부정보
재고번호
1
동력 형식
디젤
제조번호
1
기존 차주 수
1
최근검사
2025-09-05
하부 구성품 상태
good condition
엔진
Original
총 중량
28000 kg
엔진 출력
138 kW (188 마력)
엔진 제조사
Original
등록번호
1
매연 등급
Stage V / Tier V
버켓 용량
1.85 m3
트랙 폭
600 mm
최고 속도
5.50 km/h
장비크기
10260 x 3190 x 3020 mm
오리지널 컬러
Yellow
디퍼/스틱 길이
2970 mm
상태 정보/보증
1 year
제품 국가
미국
운송 조건
FCA, FOB, CIF, EXW
증명서
미국 환경 보호국(EPA), 유럽 위원회(CE)
어태치먼트
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET
TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET
CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours:24 hours, holidays and Sundays
Contact: Lily
Whatsapp: +86 17756597429
Mobile:+86 17756597429
Wechat:17756597429
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
부속품
라인 파열 밸브 붐 -> 안전선 파열 밸브 - 붐/호이스트
라인 파열 밸브 디퍼 -> 안전선 파열 밸브 - 디퍼/스틱
냉/난방 조절
Engine pre-filter
스켈레톤 버킷
회전 비컨
추가 장비
조이스틱 컨트롤
표준 굴착 버켓
기타 정보
Volvo EC250DL Excavator Parameter Configuration
specification
Power: Traditional power
Joint ventures/imports
Bucket backhoe
Tonnage (tons) 25
The working weight of the whole machine (kg) is 24600-28000
Bucket capacity (m³) 0.48-1.85
Country of origin: South Korea
performance
Rotational speed (rpm) 11.9
Rotational torque (Nm) 91.6
Travel speed (km/h) 3.5 / 5.5
Climbing ability (%) 35
Maximum traction (kN) 217
dynamical system
Engine model D7E
Rated power (kw/rpm) 138/1800
Maximum torque (N.m) 870/1350
Displacement (L) 7.1
Number of cylinders (pcs) 6
Bore × stroke (mm) 108×130
Hydraulic system
Main pump maximum flow rate (l/min) 2 x 240
Pilot oil circuit (MPa) 3.9
Working hydraulic oil circuit (Mpa) 33.3/36.3
Walking Hydraulic Circuit (Mpa) 36.3
Slewing hydraulic circuit (Mpa) 27.9
Oil capacity
Fuel tank (L) 470
Hydraulic Tank (L) 195
Hydraulic system (L) 400
Engine oil change volume (L) 32
Coolant (L) 41
Body size
Total length of transport (mm) 10260
Total width of transport (mm) 3190
Cab overall height (mm) 3020
Boarding width (mm) 2890
Track grounding length (mm) 3850
Total track length (mm) 4650
Track shoe width (mm) 600
Track gauge (mm) 2590
Minimum ground clearance (mm) 470
Counterweight ground clearance (mm) 1080
Scope of work
Maximum digging radius (mm) 10260
The maximum excavation radius of the shutdown surface (mm) is 9690
Maximum digging depth (mm) 6980
Maximum digging height (mm) 9620
Maximum unloading height (mm) 6700
Maximum vertical digging depth (mm) 5650
