구보다 U 35

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Lily Whatsapp: +86 13696501072 Mobile:+86 17756597429 Wechat:17756597429 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Kubota U35 excavator parameter configuration specification Power: Traditional power Joint ventures/imports Bucket backhoe Tonnage (tons) 3 The working weight of the whole machine (kg) is 3867 Bucket width (mm) 600/550 Bucket capacity (m³) 0.1 performance Rotational speed (rpm) 9 Travel speed (km/h) 3.0/4.6 Climbing ability (%) 30° Bucket digging force (kN) 29.5 dynamical system Engine model D1703-E4 Rated power (kw/rpm) 18.5/2200 Displacement (L) 1.647 Hydraulic system Main pump type: variable pump*2 + gear pump*2 Traveling hydraulic motor type 2-speed plunger hydraulic motor Slewing hydraulic motor type plunger hydraulic motor Oil capacity Fuel tank (L) 45.1 Body size Total length of transport (mm) 4754 Total width of transport (mm) 1700 Total height of transport (mm) 2476 Total track length (mm) 2081 Track shoe width (mm) 300 Minimum ground clearance (mm) 287 The minimum turning radius of the front working device (mm) is 2251 Rear end slewing radius (mm) 900 Scope of work Maximum digging radius (mm) 5275 Maximum digging depth (mm) 2989 Maximum digging height (mm) 4826 Maximum unloading height (mm) 3404 Maximum vertical digging depth (mm) 2318 The width × height of the bulldozer plate (mm) is 1700*341 Bulldozer shovel lifting or pushing depth (mm) 392/425
